Maksteel - Flat Healds

Maksteel Wire Healds Pvt. Ltd. is a leading Textile Weaving Machine Accessories Manufacturer in India. Maksteel has made rapid progress in the area of Jacquard Harness and parts for types of jacquard machines and suitable for all types of looms like Rapier, Air Jet, Water Jet and Label Looms.

The company successfully supplies its products in India and 22 countries over the world.

Drop Wire for Carpet Weaving

Type	Length		Flat Wire Thickness				Heald Eye
	mm	inch	0.25	0.30	0.38	0.67	5.5 x 1.2	6.5 x 1.8	8 x 2.5	8 x 3.8
C Duplex
	280	11	X	X			X	X
	331	13	X	X			X	X
	356	14	X	X			X	X
	382	15	X	X			X	X
C Simplex
	280	11	X	X			X	X	X
	331	13	X	X			X	X	X
	356	14		X			X	X	X
	382	15		X			X	X	X
	408	16		X			X	X	X
	432	17		X			X	X	X
C with Key hole
	280	11	X	X	X	X				X
	306	12	X	X	X	X				X
	331	13	X	X	X	X				X
	356	14	X	X	X					X
	382	15	X	X	X					X
J Duplex
	280	11	X	X			X	X
	331	13	X	X			X	X
J Simplex
	280	11	X	X	X		X	X	X
	331	13	X	X	X		X	X	X
	382	15	X	X	X		X	X	X
	407	16	X	X	X		X	X	X
	432	17	X	X	X		X	X	X
J With Key Hole
	331	13		X	X					X

Flat Steel Healds for Riderless Frames Stainless Steel & Nickel Plated

Type	Cross Section	Length	Yarn Eve	Eye Position			Tempored Steel
	mm	mm		Top	Bottom	Pile	Nickel Plated	Stainless Steel	Heald Rod
SIMPLEX
	2.2 x 0.30	420	5.5 x 1.2	170:250	250:170	210:210	X	X	9.0 x 1.5 9.5 x 1.5
	2.8 x 0.40	420	6.5 x 1.8	170:250	250:170	210:210	X	X
	2.5 x 0.35	520	6.0 x 1.5	220:300	300:220	260:260	X	X
	2.5 x 0.35	520	6.0 x 1.5	190:330	330:190		X	X
	3.5 x 0.40	520	6.5 x 1.8	190:330	330:190			X
	3.5 x 0.40	520	6.5 x 1.8	220:300	300:220			X
DUPLEX
	2.2 x 0.30	420	5.5 x 1.2	170:250	250:170	210:210	X		9.0 x 1.5
O SIMPLEX
	5.5 x 0.38	520	6.5 x 1.8	205:315	315:205	260:260	X		9.0 x 1.5
	5.5 x 0.38	520	6.5 x 1.8	205:315	315:205	260:260	X		9.0 x 2.5
Electrical Pile Detection
	7.5 x 0.23	420	6.0 x 1.5			210:210	X		Top: 10 x 4 Bottom: 9 x 3
	7.5 x 0.40	420	6.3 x 2.6			210:210	X
	7.5 x 0.40	480	6.3 x 2.6			240:240	X
	7.5 x 0.40	520	6.3 x 2.6			260:260	X
DUPLEX
	2.2 x 0.30	420	5.5 x 1.2	170:250	250:170	210:210	X			9.0 x 1.5
GLIDETEX
	5.5 x 0.30	420	5.5 x 1.2	170:250	250:170	210:210	X		22 x 1.7
	5.5 x 0.30	420	6.5 x 1.8	170:250	250:170	210:210	X		22 x 1.7
	5.5 x 3.0	5200	6.5 x 1.8	220:300	250:220	260:260	X		22 x 1.7

Flat Steel Healds for Pile Fabrics Stainless Steel & Nickel Plated
